| AC input frequency range |
[45, 65] Hz |
| AC input voltage Bucket |
120 V - 240 V |
| Charge voltage storage |
Normal: 13.2V High: 13.2V Li-ion: 13.5V |
| Number of fully rated charge outputs |
1 |
| No load power consumption |
1 W |
| Maximum humidity (non-condensing) |
95 % |
| Low current starter battery output (4A) |
Yes |
| Lithium compatible |
Yes |
| Linearly Derating between 40 and 60 °C |
20 % |
| Fully programable |
Yes |
| Maximum efficiency |
94 % |
| DC input voltage range |
[90, 375] VDC |
| Data Communication |
VE.Direct,Bluetooth |
| Charge voltage float |
Normal: 13.8V High: 13.8V Li-ion: 13.5V |
| Charge voltage Absorption |
Normal: 14.4V High: 14.7V Lithium: 14.2V |
| Charge Current Normal Mode (Nominal value) |
50 A |
| Charge Current Low Mode |
25 A |
| Charge algorithm |
Adaptive, 6-stage |
| Bluetooth |
Yes, -4dBm, 2402 – 2480 MHz |
| Nominal battery voltage |
12 V |
| Back current drain |
1 mA |
| AC input voltage range |
[85, 250] VAC |
| Number of charge outputs |
2 |
| Temperature Sensor |
Optional (Smart Battery Sense) |
| Temperature compensation (adjustable) |
-16 mV/°C |
| Remote on/off terminal |
Yes |
| Protections |
Battery reverse polarity (fuse not user accessible),Output short-circuit,Over temperature |
| Programable relay |
SPDT - 5 A up to 250 VAC / 5 A up to 28 VDC |
| Power supply mode |
Yes |
| Power factor |
1 |
| Ouput fully rated up to |
40 °C |
| Operating temperature range |
[-20, 60] °C |
