Victron Orion-Tr 48/12-20A (240W) Isolated DC-DC Converter

Victron DC-DC converters

$113.90

Price is the manufacturer’s advertised price. Shipping and any applicable Georgia sales tax are calculated separately at checkout.

We confirm stock and lead time with the manufacturer when your order comes in, and email you before anything ships.

Ships for about $18.00 per unit, at cost.

Add professional installation

Equipment here is sold at MAP; installation is quoted separately so labor stays its own line item. Price a fitted system in about two minutes.

Detailed specifications published by Victron.

Technical for Victron Orion-Tr 48/12-20A (240W) Isolated DC-DC Converter
Bluetooth	No
Continuous output current	20 A
Continuous output power at 25°C	280 W
Continuous output power at 40°C	240 W
Galvanic isolation	Yes
Standby current Consumption	0.2 mA
Under voltage restart	30 V
Under voltage shutdown	28 V
No-load current consumption	80 mA
Input voltage range	[32, 70] V
Isolation	200 VDC
Maximum efficiency	87
Maximum humidity (non-condensing)	95 %
Maximum Output Current	25 A
Maximum continuous short-circuit current	50 A
Operating temperature rang	[-20, 55] °C
Output voltage	12.2 V
Output Voltage Noise	2 mVrms
Output voltage range	[10, 15] V
Output Voltage Tolerance	200 mVrms
Remote on/off terminal	Yes

Connections for Victron Orion-Tr 48/12-20A (240W) Isolated DC-DC Converter
DC connection terminal type	Screw terminals 16 mm² (6 AWG)
Remote On Off Terminal Connection	Screw terminal two pole
