Victron SmartSolar MPPT 100/50 Solar Charge Controller – 50A Bluetooth MPPT Controller for RV Marine & Off-Grid Solar

Victron Solar charge controllers

$193.80

Price is the manufacturer’s advertised price. Shipping and any applicable Georgia sales tax are calculated separately at checkout.

We confirm stock and lead time with the manufacturer when your order comes in, and email you before anything ships.

Ships for about $18.00 per unit, at cost.

Add professional installation

Equipment here is sold at MAP; installation is quoted separately so labor stays its own line item. Price a fitted system in about two minutes.

Detailed specifications published by Victron.

Technical for Victron SmartSolar MPPT 100/50 Solar Charge Controller – 50A Bluetooth MPPT Controller for RV Marine & Off-Grid Solar
Maximum efficiency	98 %
Maximum humidity (non-condensing)	95 %
Maximum PV Open Circuit Voltage	100 V
Maximum PV short circuit current per tracker	60 A
Nominal PV power at 12 V	700 W
Nominal PV power at 24 V	1,400 W
Number of trackers	1
Operating temperature range	[-30, 60] °C
Protections	Output short-circuit,Excessive temperature,PV reverse polarity
Rated Charge Current	50 A
Self-consumption	12V: 30mA / 24V: 20mA
Start-up PV DC voltage	The PV voltage must exceed Vbat + 5V for the controller to start. Thereafter the minimum PV voltage is Vbat + 1V
Temperature Compensation at 12V	-16 mV/°C
Temperature Compensation at 24V	-32 mV/°C
Temperature Sensor	Optional (Smart Battery Sense)
Battery voltage	12V / 24V (
Bluetooth	Yes
Charge algorithm	Multi-stage adaptive (adjustable)
Charge voltage absorption	14.4V / 28.8V (adjustable)
Charge voltage float	13.8V / 27.6V (adjustable)
Data Communication	Bluetooth,VE.Direct

Connections for Victron SmartSolar MPPT 100/50 Solar Charge Controller – 50A Bluetooth MPPT Controller for RV Marine & Off-Grid Solar
PV connection terminal type	Screw terminals 16 mm² (6 AWG)
Battery connection terminal type	Screw terminals 16 mm² (6 AWG)

Enclosure for Victron SmartSolar MPPT 100/50 Solar Charge Controller – 50A Bluetooth MPPT Controller for RV Marine & Off-Grid Solar
Width	186 mm
Weight	1.3 kg
Protection Category	IP22 (connection area),IP43 (electronic components)
Height	130 mm
Depth	70 mm
Colour	Blue (RAL 5012)

Standards for Victron SmartSolar MPPT 100/50 Solar Charge Controller – 50A Bluetooth MPPT Controller for RV Marine & Off-Grid Solar
Safety	UL 1741,CSA C22.2,EN-IEC 62109-1
