Specifications
Detailed specifications published by EPOCH.
Overview
| Brand | EPOCH |
|---|---|
| SKU | B24100A-C |
| Nominal voltage | 24 |
| Energy (kWh) | 2.56 |
Configuration
| Cell Configuration | 8S |
|---|---|
| Chemistry | LiFePO4 |
Voltage
| Voltage | 24V |
|---|---|
| Max Charge Voltage | 29.2V |
| Operating Voltage Range | 20 - 29.2V |
Current
| Ah Capacity | 100Ah |
|---|---|
| Max Continuous Discharge Amps | 120A |
| Max Charge Current Amps | 150A (10 Seconds) |
| Max Discharge Peak Current Amps | 200A (60 Seconds) |
| Series | Parallel | Max (2) in Series | Max (4) in Parallel |
Temperature
| Charge Temp Range | -20°C (-4°F) / 55°C (131°F) (with heating) |
|---|---|
| Discharge Temp Range | -20°C (-4°F) / 60°C (140°F) |
| Storage Temp | 0°C (32°F) / 35°C (95°F) (Max 12 Months) |
Weight & dimensions
| Weight | 48.5 lb |
|---|---|
| Dimensions (L x W x H) | 13 x 10.25 x 11 in |
Protection
| BMS protection | BMS (Battery Management System) Over Voltage, Under Voltage, Over-Current, Short Circuit, Over Temperature, Under Temperature |
|---|
