36V 100Ah LiFePO4 Lithium Battery (3.84kWh)

Overview

Overview for 36V 100Ah LiFePO4 Lithium Battery (3.84kWh)

Brand	EPOCH
SKU	B36100A-A
Nominal voltage	36
Energy (kWh)	3.84

Configuration

Configuration for 36V 100Ah LiFePO4 Lithium Battery (3.84kWh)

Cell Configuration	12S
Chemistry	LiFePO4

Voltage

Voltage for 36V 100Ah LiFePO4 Lithium Battery (3.84kWh)

Voltage	36V
Max Charge Voltage	43.8V
Operating Voltage Range	30 - 43.8V

Current

Current for 36V 100Ah LiFePO4 Lithium Battery (3.84kWh)

Ah Capacity	100Ah
Max Continuous Discharge Amps	120A
Max Charge Current Amps	150A (10 Seconds)
Max Discharge Peak Current Amps	200A (60 Seconds)
Series | Parallel	Max (4) in Parallel

Temperature

Temperature for 36V 100Ah LiFePO4 Lithium Battery (3.84kWh)

Charge Temp Range	-20°C (-4°F) / 55°C (131°F) (with heating)
Discharge Temp Range	-20°C (-4°F) / 60°C (140°F)
Storage Temp	0°C (32°F) / 35°C (95°F) (Max 12 Months)

Weight & dimensions

Weight & dimensions for 36V 100Ah LiFePO4 Lithium Battery (3.84kWh)

Weight	75 lb
Dimensions (L x W x H)	20 x 10.25 x 11 in

Protection

Protection for 36V 100Ah LiFePO4 Lithium Battery (3.84kWh)

BMS protection	BMS (Battery Management System) Over Voltage, Under Voltage, Over-Current, Short Circuit, Over Temperature, Under Temperature
