48V 100Ah V2-T Elite Series LiFePO4 Battery (5.12kWh)

Overview

Overview for 48V 100Ah V2-T Elite Series LiFePO4 Battery (5.12kWh)

Brand	EPOCH
SKU	C48100A-A
Nominal voltage	48
Energy (kWh)	5.12
Heated	Yes
Series	V2-T Elite

Configuration

Configuration for 48V 100Ah V2-T Elite Series LiFePO4 Battery (5.12kWh)

Cell Configuration	16S1P
Chemistry	LiFePO4

Voltage

Voltage for 48V 100Ah V2-T Elite Series LiFePO4 Battery (5.12kWh)

Voltage	51.2V
Max Charge Voltage	58.4V
Operating Voltage Range	40.0V - 58.4V

Current

Current for 48V 100Ah V2-T Elite Series LiFePO4 Battery (5.12kWh)

Ah Capacity	100Ah
Max Continuous Discharge Amps	150A
Max Charge Current Amps	100A
Max Discharge Peak Current Amps	300A @ 30sec
Series | Parallel	Max (16) in Parallel, Plug & Play

Temperature

Temperature for 48V 100Ah V2-T Elite Series LiFePO4 Battery (5.12kWh)

Charge Temp Range	-30°C (-22°F) / 55°C (131°F) (with self-heating)
Discharge Temp Range	-20°C (-4°F) / 55°C (131°F)
Storage Temp	0°C (32°F) / 35°C (95°F)

Weight & dimensions

Weight & dimensions for 48V 100Ah V2-T Elite Series LiFePO4 Battery (5.12kWh)

Weight	97lbs
Dimensions (L x W x H)	20.75 x 8.5 x 12 in

Protection

Protection for 48V 100Ah V2-T Elite Series LiFePO4 Battery (5.12kWh)

BMS protection	250A Class T Fuse, BMS (Battery Management System) Over Voltage, Under Voltage, Over-Current, Shot Circuit, Over Temperature, Under Temperature
